Grapples
Demolition & Sorting Grapples
Montabert HCG Demolition & Sorting Grapples are engineered for heavy-duty demolition, sorting, loading, dismantling, and recycling applications. Designed with reinforced steel construction, continuous hydraulic rotation, and powerful gripping force, these grapples deliver dependable material handling performance across a wide range of carrier sizes.
Overview
The Montabert HCG Grapple lineup is designed to provide strong gripping force, reliable hydraulic performance, and long-term durability for demanding demolition and recycling environments. These grapples are ideal for material sorting, scrap handling, concrete cleanup, timber movement, and heavy construction applications.
Key Features
- Standard 360° continuous hydraulic rotation for improved maneuverability.
- Overload protection, ending position limiter, and dampener for safer operation.
- Structure and shells manufactured from reinforced 400HB steel.
- Blades built from durable 500HB steel for increased wear resistance.
- Field-replaceable and reversible lower blades for easier maintenance.
- Designed for demolition, sorting, dismantling, recycling, and loading applications.
Built for Heavy Material Handling
Montabert HCG grapples are engineered for contractors who require dependable material handling performance in demanding environments. Their heavy-duty construction and efficient hydraulic operation help improve productivity while reducing downtime in demolition and recycling operations.
Common Applications
Montabert Demolition & Sorting Grapples are commonly used in demolition, recycling, scrap handling, forestry, and construction applications where material control and gripping force are critical.
Demolition
Handle demolition debris, concrete, and structural material safely and efficiently.
Sorting
Separate mixed materials for recycling and processing operations.
Scrap Handling
Move and process scrap metal and recyclable materials with strong gripping force.
Loading & Unloading
Improve material handling efficiency on construction and demolition sites.
Forestry
Handle timber, brush, and land clearing material in demanding environments.
Recycling
Support concrete recycling and material recovery operations efficiently.
HCG Grapple Comparison Table
Compare carrier compatibility, operating weight, load capacity, oil flow, and closing force across the Montabert HCG Demolition & Sorting Grapple lineup.
| Specification | HCG 7-250 | HCG 10-400 | HCG 20-600 | HCG 23-700 | HCG 25-800 |
|---|---|---|---|---|---|
| Carrier Weight (Tons) | 7 - 10 | 9 - 15 | 14 - 22 | 17 - 25 | 21 - 29 |
| Operating Weight (lbs) | 1,140 | 1,698 | 2,579 | 3,086 | 3,748 |
| Load Capacity (ft³) | 8.8 | 13.7 | 21.2 | 24.7 | 28.2 |
| Closing Force (T) | 2.7 | 4 | 5.1 | 5.3 | 6.3 |
| Oil Flow Max (GPM) | 15.8 | 18.5 | 21.1 | 21.1 | 26.4 |
| Rotation Pressure Max (PSI) | 2,030 | 2,030 | 1,305 | 1,305 | 1,305 |
| Specification | HCG 30-1000 | HCG 32-1200 | HCG 45-1100 | HCG 45-1500 | HCG 75-2700 |
|---|---|---|---|---|---|
| Carrier Weight (Tons) | 25 - 37 | 25 - 37 | 35 - 60 | 35 - 60 | 60 - 100 |
| Operating Weight (lbs) | 4,409 | 4,564 | 6,152 | 6,614 | 11,023 |
| Load Capacity (ft³) | 35.3 | 42.4 | 38.8 | 53 | 95.3 |
| Closing Force (T) | 6.5 | 6.5 | 9.1 | 9.1 | 17.3 |
| Oil Flow Max (GPM) | 31.7 | 31.7 | 44.9 | 44.9 | 66 |
| Rotation Pressure Max (PSI) | 1,305 | 1,305 | 1,885 | 1,885 | 1,885 |
Specifications are based on the current Montabert HCG Grapple specification sheet. Contact BHE Attachments to confirm carrier compatibility, mounting configuration, and hydraulic requirements before ordering.
Why Choose Montabert HCG Grapples?
Montabert HCG grapples combine heavy-duty steel construction, continuous rotation capability, and strong gripping force to help contractors improve efficiency in demolition, sorting, and recycling operations. Their replaceable wear components and durable design help reduce downtime and maintenance costs over time.
