XL Breakers
XL Series Breakers
The Montabert XL Series hydraulic breakers deliver reliable performance, nitrogen chamber efficiency, and reinforced durability for demolition, quarrying, trenching, construction, excavation, and recycling applications. Designed and manufactured in France, the XL Series combines Montabert engineering with economical operation and simplified maintenance for carriers from 11 to 38 tons.
Overview
Montabert XL Series breakers feature nitrogen chamber technology, reinforced housings, blank firing protection, soundproofing, energy recovery systems, and simplified maintenance access. Engineered for dependable productivity and reduced operating costs, XL breakers are ideal for demanding construction and demolition applications.
Nitrogen Chamber Technology
High-performance seals help maintain stable nitrogen pressure and reduce maintenance downtime.
Protected Power Cell
Fully dampened power cell protects both the carrier and the operator from excessive vibration.
Energy Recovery System
Efficient hydraulic design maximizes impact energy and improves operating efficiency.
Blank Firing Protection
Protects internal components and extends breaker service life during operation.
Automatic Lubrication Ready
Available lubrication systems help optimize grease delivery and reduce wear.
Low Operating Costs
Built for productivity, durability, and economical long-term ownership.
Applications
The Montabert XL Series breakers are built for a wide range of demanding applications across multiple industries.
Demolition
Concrete breaking and structural demolition applications.
Construction
General construction and infrastructure projects.
Excavation
Rock trenching and excavation support operations.
Quarrying
Primary and secondary rock breaking in quarry environments.
Recycling
Material reduction and recycling facility operations.
Civil Engineering
Heavy infrastructure and utility construction projects.
XL Series Specification Comparison
Compare Montabert XL Series hydraulic breaker models and specifications below.
| Specification | XL1000 | XL1300 | XL1700 | XL1900 | XL2700 |
|---|---|---|---|---|---|
| Carrier Weight Range | 11 - 17 Tons | 15 - 22 Tons | 18 - 28 Tons | 21 - 31 Tons | 28 - 38 Tons |
| Operating Weight | 843 kg / 1,857 lbs | 1,080 kg / 2,261 lbs | 1,436 kg / 3,158 lbs | 1,745 kg / 3,846 lbs | 2,310 kg / 5,093 lbs |
| Oil Flow Range | 70 - 120 L/min | 90 - 140 L/min | 100 - 150 L/min | 120 - 180 L/min | 150 - 240 L/min |
| Oil Flow Range (GPM) | 18.5 - 31.7 | 23.8 - 37 | 26.4 - 39.6 | 31.7 - 47.5 | 39.6 - 63.4 |
| Operating Pressure | 170 bar / 2,466 PSI | 170 bar / 2,466 PSI | 180 bar / 2,611 PSI | 180 bar / 2,611 PSI | 180 bar / 2,611 PSI |
| Back Pressure | 20 bar / 290 PSI | 20 bar / 290 PSI | 17 bar / 247 PSI | 17 bar / 247 PSI | 17 bar / 247 PSI |
| Input Power | 34 kW | 39.6 kW | 45 kW | 54 kW | 72 kW |
| Striking Frequency | 400 - 750 BPM | 355 - 600 BPM | 340 - 560 BPM | 360 - 630 BPM | 335 - 630 BPM |
| Tool Diameter | 106 mm / 4.17 in | 124 mm / 4.88 in | 137 mm / 5.39 in | 142 mm / 5.59 in | 156 mm / 6.14 in |
| Noise Level /10m | 91 dB LWA | 96 dB LWA | 89 dB LWA | 101 dB LWA | 99 dB LWA |
| Soundproofing | Standard | Standard | Standard | Standard | Standard |
| Manual Lubrication | Standard | Standard | Standard | Standard | Standard |
| Inspection Kit | Standard | Standard | Standard | Standard | Standard |
Why Choose Montabert XL Breakers?
Engineered for Productivity
XL Series breakers combine efficient hydraulic performance, simplified maintenance, and reinforced durability to help contractors maximize uptime and jobsite productivity across demanding applications.
Built with Montabert Technology
Every XL breaker benefits from Montabert engineering, including energy recovery systems, blank firing protection, reinforced housings, soundproofing, and premium nitrogen chamber technology.
Need help selecting the correct XL breaker?
Contact Brown's Heavy Equipment for carrier compatibility assistance, hydraulic setup recommendations, pricing, and availability for the Montabert XL Series.
