Doosan DX300LC Compatible Attachments
The Doosan DX300LC is a 30-ton class hydraulic excavator designed for high productivity, improved fuel economy, and versatile attachment performance. Powered by the new generation Doosan DL08 Common Rail engine with e-EPOS electronic control, this machine delivers 197 hp at 1,900 rpm with optimized hydraulic flow for demanding excavation and earthmoving applications.
Attachment fitment for the Doosan DX300LC should be verified against the carrier's operating weight of 29,300 kg to 30,500 kg (64,550 lb to 67,240 lb), hydraulic flow of 2 x 247 L/min, auxiliary circuit configuration with button control of flow, pin dimensions, coupler style, and the specific material conditions being worked. BHE Attachments can help review these details before quoting or installing an attachment.
Doosan DX300LC Attachment Matches
The attachment categories below are organized for the Doosan DX300LC carrier class. Final compatibility should be confirmed using the exact machine configuration, hydraulic setup, mounting dimensions, coupler style, and job application.
Hydraulic Breakers for Concrete, Rock & Quarry Work
Hydraulic breakers and hammers are a primary attachment match for the Doosan DX300LC when the job requires concrete breaking, rock breaking, quarry work, asphalt removal, trenching through hard material, or demolition support. The machine comes standard with hydraulic piping for breaker operation.
Montabert breaker models previously identified for review with this carrier class include V32, XL1900, V1800, V45, V2500, and XL2600. Final selection should be based on the carrier's hydraulic flow of 2 x 247 L/min, operating pressure up to 343 bar in power mode, breaker weight, bracket setup, and duty cycle.
Digging, Trenching, Grading & Cleanup Buckets
Bucket selection for the Doosan DX300LC should match the work being performed. A wide range of buckets from 0.64 m3 to 1.75 m3 are available for digging everything from basic topsoil to extreme harsh material like ore and high quartzite granite. The bucket digging force of 199 kN supports aggressive excavation.
Bucket fitment should be checked by pin diameter, pin spread, stick width, coupler configuration, width, capacity, tooth style, edge type, and material density up to 2,000 kg/m3. Arm lengths of 2.5 m, 3.1 m, and 3.75 m support different reach and digging depth requirements.
Couplers, Thumbs & Grapples
Couplers, thumbs, and grapples can improve the Doosan DX300LC's usefulness for attachment changes, debris handling, brush handling, demolition cleanup, pipe handling, and sorting material on job sites. The control levers have additional electrical buttons for controlling additional equipment like grabs, crushers, and grippers.
These tools should be reviewed for stick geometry, thumb length, coupler type, hydraulic plumbing, bracket style, and the machine's lifting and stability limits. The e-EPOS system enables precise flow regulation for auxiliary equipment.
Plate Compactors for Trench & Backfill Work
Plate compactors can be reviewed for the Doosan DX300LC when the work involves trench compaction, utility installation, backfill compaction, road repair, or site preparation. The e-EPOS system allows button control of flow in auxiliary equipment circuits for precise compactor operation.
Compactor compatibility should be confirmed by attachment weight, hydraulic flow, pressure range up to 324 bar in normal mode, mounting bracket, hose routing, and the compaction area required for the job.
Rippers & Specialty Excavator Tools
Rippers and specialty tools may be considered for the Doosan DX300LC when the machine is working in compacted soil, frost, hardpan, rocky material, or site preparation conditions where a standard bucket is not the most efficient first tool. The one-touch power boost provides extra breakout force when needed.
Tool selection should be based on material type, breakout needs, carrier size, mounting setup, and whether the tool will be used before bucket excavation or as part of demolition cleanup. The machine's 199 kN bucket digging force and 164 kN arm digging force provide substantial breakout capability.
Doosan DX300LC Jobsite Applications
These application notes help connect the Doosan DX300LC to the attachment type most often used for each kind of work.
Concrete & Rock Breaking
Use a properly sized hydraulic breaker, such as the Montabert V32, XL1900, V1800, V45, V2500, or XL2600, when the Doosan DX300LC is assigned to concrete removal, rock breaking, quarry work, asphalt removal, or demolition support.
Excavation & Trenching
Use digging buckets when the machine is being used for utility installation, drainage work, foundations, roadwork, and general excavation with its 7,360 mm maximum digging depth with 3.1 m arm.
Grading & Cleanup
Use grading or cleanup buckets when the job requires finish shaping, slope work, ditch cleaning, loose material handling, or surface cleanup.
Material Handling
Use thumbs, grapples, or coupler-supported tools when the Doosan DX300LC needs to handle debris, brush, pipe, or irregular objects on job sites with its e-EPOS controlled auxiliary circuits.
Compaction
Use a plate compactor when the machine is supporting trench backfill, utility repair, road repair, or site preparation where controlled compaction is needed.
Hard Ground Preparation
Use a ripper or specialty ground-engagement tool when compacted soil, frost, hardpan, or rocky material needs to be loosened before excavation.
Attachment Fitment Factors
The Doosan DX300LC should be matched with attachments using both machine specifications and jobsite requirements. These checks help reduce incorrect fitment, poor performance, and unnecessary attachment wear.
Machine & Mounting Requirements
- Confirm carrier operating weight of 29,300 kg to 30,500 kg (64,550 lb to 67,240 lb) with standard equipment and operator.
- Check pin diameter, pin spread, stick width, and coupler configuration for quick coupler or pin-on setup.
- Match the attachment bracket to the Doosan DX300LC mounting setup with 6.245 m boom.
- Review attachment weight against machine lifting capacity and stability limits.
- For buckets, confirm width, capacity from 0.64 m3 to 1.75 m3, tooth style, edge type, and duty rating for material density.
Hydraulic & Application Requirements
- Confirm hydraulic flow of 2 x 247 L/min and pressure up to 343 bar in power mode for powered attachments.
- Verify e-EPOS controlled auxiliary circuit setup with button control of flow, and hose routing for breaker piping.
- Select breaker tools based on material, including moil point, chisel, blunt, or specialty tools.
- Match the attachment to the material being worked: concrete, rock, asphalt, soil, brush, or demolition debris.
- Review duty cycle, production needs, operator use, and jobsite conditions before final selection.
Doosan DX300LC Attachment Overview
Use this table as a quick reference for matching common Doosan DX300LC attachment categories to their main purpose.
| Carrier Model | Attachment Type | Best Use | Fitment Checks | Typical Applications |
|---|---|---|---|---|
| Doosan DX300LC | Hydraulic Breakers & Hammers | Breaking concrete, rock, asphalt, and hard material. | Hydraulic flow 2 x 247 L/min, pressure up to 343 bar, breaker weight, bracket, tool type, and duty cycle. | Demolition, quarry work, road repair, concrete removal, rock breaking. |
| Doosan DX300LC | Excavator Buckets | Digging, trenching, grading, ditching, cleanup, and material loading. | Pin dimensions, coupler setup, bucket width, capacity 0.64-1.75 m3, tooth style, and edge type. | Excavation, utility work, grading, drainage, site development. |
| Doosan DX300LC | Couplers, Thumbs & Grapples | Changing attachments and handling loose, bulky, or irregular material. | Stick geometry, coupler type, thumb length, hydraulic plumbing, and lift limits. | Debris handling, brush handling, pipe handling, demolition cleanup. |
| Doosan DX300LC | Plate Compactors | Compacting trench backfill, soil, and utility repair areas. | Hydraulic flow, pressure range, compactor weight, bracket, and hose routing. | Trench compaction, road repair, backfill, utility installation, site prep. |
| Doosan DX300LC | Rippers & Specialty Tools | Loosening compacted or hard material before excavation. | Carrier size, mounting setup, tooth design, material conditions, and breakout needs. | Hardpan, frost, rocky soil, site prep, pre-excavation ripping. |
Final compatibility can vary by Doosan DX300LC configuration, coupler, pin dimensions, hydraulic setup, and job application. Always verify fitment before purchasing or installing an attachment.
Find the Right Attachment for Your Doosan DX300LC
BHE Attachments can help compare hydraulic breakers, buckets, couplers, thumbs, compactors, grapples, rippers, and specialty tools for the Doosan DX300LC. The best attachment depends on whether the machine will be breaking, digging, grading, compacting, handling material, or preparing hard ground.
To narrow the right option, provide the machine serial number if available, current coupler setup, hydraulic flow and pressure information, pin dimensions, and a short description of the work being performed.
Need Help Confirming Compatibility?
BHE Attachments can review your Doosan DX300LC specifications, hydraulic requirements, mounting setup, pin dimensions, coupler configuration, and application needs to help identify the right attachment category and product fit.
Ready to quote attachments for your Doosan DX300LC?
Send the machine setup and job application to BHE Attachments so the attachment recommendation can be matched to the Doosan DX300LC carrier class, hydraulic setup, mounting requirements, and work conditions.
