Micro CPA 360
Montabert Micro CPA 360 Drilling Attachment
The Montabert Micro CPA 360 is a compact excavator-mounted drilling attachment that combines proven Montabert hydraulic drifter technology with a full 360-degree rotating head for greater positioning flexibility. Designed for compact excavators, it allows contractors to perform accurate rock drilling, anchoring, trenching, utility installation, and civil engineering work while maximizing excavator versatility and reducing the need for dedicated drilling equipment.
Micro CPA 360 Overview
The Micro CPA 360 expands the capabilities of compact excavators by providing precise drilling performance together with continuous rotational positioning. Its rotating head makes it easier to align the drill in confined work areas and on challenging terrain while maintaining the productivity, reliability, and versatility expected from Montabert drilling attachments.
Key Features
- Compact excavator-mounted drilling attachment.
- 360-degree rotating drilling head for greater positioning flexibility.
- Powered by a genuine Montabert hydraulic drifter.
- Designed for accurate rock drilling and anchoring applications.
- Excellent access in confined and restricted work areas.
- Suitable for utility, infrastructure, and civil engineering projects.
- Helps maximize excavator utilization across multiple jobsite tasks.
- Built for dependable performance with straightforward maintenance.
Designed for Compact Excavators
Engineered for carriers in the 10–14 tonne class, the Micro CPA 360 allows contractors to complete drilling operations using the same excavator already working on the project. The rotating head improves drilling access while helping reduce machine repositioning and increasing overall jobsite efficiency.
Common Applications
The Montabert Micro CPA 360 is engineered for contractors who require precise drilling performance together with greater positioning flexibility. Its rotating drilling head allows operators to reach drilling locations more easily while improving productivity on construction, infrastructure, and utility projects.
Utility Construction
Drill accurate holes for underground utilities, telecommunications, water systems, electrical infrastructure, and municipal improvement projects.
Anchoring
Install rock anchors, retaining wall anchors, and reinforcement systems for civil engineering and slope stabilization applications.
Foundation Drilling
Prepare drilled holes for foundations, posts, fencing, light structural supports, and construction projects requiring drilling accuracy.
Rock Drilling
Perform controlled drilling in rock formations for trench preparation, quarry support, excavation, and general construction work.
Restricted Access Jobsites
The compact design and rotating drilling head provide excellent access where larger drilling equipment cannot operate efficiently.
Civil Engineering
Suitable for bridge construction, highway improvements, infrastructure projects, retaining walls, and other demanding engineering applications.
Why Choose the Micro CPA 360?
The Micro CPA 360 combines compact dimensions with enhanced drilling flexibility. Its continuous 360-degree rotation allows operators to position the drilling attachment more efficiently, reducing excavator repositioning while improving productivity on challenging jobsites.
Performance Benefits
- 360-degree rotating drilling head improves positioning flexibility.
- Designed specifically for compact excavators.
- Powered by proven Montabert hydraulic drifter technology.
- Excellent drilling accuracy for demanding applications.
- Reduces excavator repositioning during drilling operations.
- Suitable for multiple drilling applications using one carrier.
- Compact size improves accessibility on confined jobsites.
- Built for dependable operation with simplified maintenance.
Increase Excavator Productivity
Instead of transporting dedicated drilling equipment, contractors can equip a compatible excavator with the Micro CPA 360 to complete drilling, excavation, and material handling using a single machine. This approach helps reduce fleet costs while improving overall equipment utilization.
Micro CPA 360 Specifications
The Montabert Micro CPA 360 is designed for compact excavators requiring greater drilling flexibility through its rotating drilling head. Review the specifications below to verify carrier compatibility and drilling performance for your application.
| Specification | Micro CPA 360 |
|---|---|
| Recommended Carrier Weight | 10–14 t |
| Operating Weight | 780 kg (1,720 lb) |
| Hydraulic Oil Flow | 60–95 L/min (15.9–25.1 GPM) |
| Hydraulic Drifter | Montabert HC20 / HC25 |
| Hole Diameter Range | 26–51 mm (1–2 in) |
| Maximum Hole Depth | 3.2 m (10.5 ft) |
| Rotation | 360° Continuous Rotation |
| Typical Applications | Utility construction, anchoring, foundation drilling, trenching, infrastructure projects, and precision rock drilling. |
Specifications are provided as a general reference. Final attachment selection should be confirmed using carrier operating weight, available hydraulic flow, drilling requirements, and the intended application.
Micro CPA 360 Compared with the CPA Series
The Micro CPA 360 fills the gap between compact drilling attachments and larger CPA models by combining a lightweight design with full rotational positioning for increased flexibility on demanding jobsites.
| Specification | Micro CPA | Micro CPA 360 | CPA222E | CPA225E | CPA250 | CPA295 |
|---|---|---|---|---|---|---|
| Carrier Weight (t) | 7–10 | 10–14 | 20–27 | 20–27 | 25–35 | 25–35 |
| Operating Weight (kg) | 540–690 | 780 | 1,610 | 1,610 | 2,550 | 2,740 |
| Hole Diameter | 26–51 mm | 26–51 mm | 36–76 mm | 36–76 mm | 64–76 mm | 76–105 mm |
| Maximum Hole Depth | 3.2 m | 3.2 m | 7.4 m | 7.4 m | 21 m | 21 m |
| Rotation Capability | Fixed | 360° | Fixed | Fixed | Fixed | Fixed |
| Typical Applications | Utility & Civil | Utility & Infrastructure | Infrastructure | Heavy Construction | Quarry | Mining & Quarry |
Why Choose the Montabert Micro CPA 360?
The Montabert Micro CPA 360 delivers the precision and reliability of Montabert drilling technology while adding continuous 360-degree rotation for improved attachment positioning. This combination allows operators to drill more efficiently in confined spaces, reduce machine repositioning, and complete demanding drilling applications with greater productivity.
- Continuous 360-degree rotation for precise drill positioning.
- Designed for compact excavators in the 10–14 tonne class.
- Powered by proven Montabert HC20/HC25 hydraulic drifter technology.
- Excellent for utility, civil engineering, and infrastructure drilling.
- Compact design improves access in restricted work areas.
- Produces accurate drilling results with dependable performance.
- Reduces the need for dedicated drilling equipment on many projects.
- Allows one excavator to perform excavation, drilling, and material handling.
- Built for durability with simplified maintenance requirements.
- Supported by the experienced BHE Attachments sales and service team.
Need Help Selecting the Right CPA Attachment?
BHE Attachments can help determine whether the Micro CPA 360 is the best solution for your excavator and drilling application. Our specialists evaluate carrier size, hydraulic capacity, drilling diameter requirements, and project conditions to recommend the most suitable Montabert drilling attachment.
We also provide assistance with attachment compatibility, hydraulic requirements, replacement parts, and selecting the appropriate model from the complete Montabert CPA drilling attachment range.
Talk to BHE About the Montabert Micro CPA 360
The Montabert Micro CPA 360 combines compact excavator compatibility with continuous rotational positioning to deliver accurate drilling performance across utility, construction, anchoring, and civil engineering applications. Contact BHE Attachments today for pricing, expert guidance, and help selecting the right Montabert drilling attachment for your fleet.
